TPE-E Ultraflex +

Name: TPE-E Ultraflex +
SKU: ULTRA+
Availability: InStock

Product ID: ULTRA+

User Unavailable

Visit Store

Rated 1 out of 5

0 reviews

UltrafleXX+ exhibits exceptional printability, attributable to our proprietary formulation specifically engineered for 3D printing applications. This material is suitable for a wide range of industrial sectors due to its superior resistance to mechanical stress and oil aggression.

It demonstrates high elastic recovery, allowing printed objects to swiftly return to their original shape. The material operates effectively across a broad temperature spectrum, from -50°C to 120°C, making it versatile for various applications.

No support file available

SUGGESTED PRINT SETS (1)
Suggested print sets	unit	value	test method
extruder temp	C°	215-235	internal
plate temp	C°	45-90	internal
min. nozzle diameter	mm	0.35	internal
fan	%	0-30	internal
print speed	mm/1°	25-40	internal
PROPERTY
Physical
Specific gravity	g/cm3	1.11	ISO 1183
Water absorption	%	0.8	ISO 62
Mechanical at 23°C / 50% rh
Tensile strain at break	%	>825	ISO 527
Charpy impact (23°C)	kJ/m2	no break	ISO 179
Charpy impact (-30°C)	kJ/m2	no break	ISO 179
Flexural modulus	MPa	32	ISO 178
Hardness	sh/A - sh/D	90-42	ISO 62
Thermal
Vicat softening temp.	°C	185	ISO 306
